Table 13. Configuration 3: R2b + R3a (continued)
Card type Slot priority Maximum number of cards
Mellanox (NIC: 25 Gb) 2, 1, 3 3
Dell Front PERC
Internal Slot
1
Table 14. Configuration 4: R1a + R4c +R4d
Card type Slot priority Maximum number of cards
Dell BOSS Adapter 2, 1 1
T4 GPU (Nvidia) 2 ,1 2
Mellanox (NIC: 100 Gb) 2, 1 2
Mellanox (NIC: 25 Gb) 2, 1 2
Broadcom (NIC: 25 Gb) 2, 1 2
Emulex (HBA: FC32) 2, 1 2
QLogic (HBA: FC32) 2, 1 2
Emulex (HBA: FC16) 2, 1 2
QLogic (HBA: FC16) 2, 1 2
FOXCONN (HBA355E) 2, 1 2
Dell PERC Adapter 2, 1 2
FOXCONN (Front PERC, 500)
Not supported
0
FOXCONN (Front PERC)
Internal Slot
1
Dell Front PERC
Internal Slot
1
Broadcom (OCP: 25 Gb)
Internal Slot
1
Mellanox (OCP: 25 Gb)
Internal Slot
1
Table 15. Configuration 5: R3a
Card type Slot priority Maximum number of cards
GPU (Nvidia) 3 1
Mellanox (NIC: 100 Gb) 3 1
Mellanox (NIC: 50 Gb) 3 1
Mellanox (NIC: 25 Gb) 3 1
Broadcom (NIC: 25 Gb) 3 1
Emulex (HBA: FC32) 3 1
QLogic (HBA: FC32) 3 1
Emulex (HBA: FC16) 3 1
QLogic (HBA: FC16) 3 1
FOXCONN (HBA355E) 3 1
Inventec (BOSS) 3 1
Inventec (Front PERC)
Internal Slot
1
