computer. For additional safety best practices information, see the Regulatory Compliance Homepage on
www.dell.com at: www.dell.com/regulatory_compliance.
1. Place the IEEE 1394 card in at an angle to fit the connector into the base assembly.
2. Replace the M2 x 3-mm screw.
3. Replace the left I/O board (see Replacing the Left I/O Board
).
4. Replace the card cage (see Replacing the Card Cage
).
5. Replace the palm rest assembly (Replacing the Palm Rest Assembly
).
6. Replace the keyboard (see Replacing the Keyboard
).
7. Replace the LED cover (see Replacing the LED Cover
).
8. Replace the display assembly (see Replacing the Edge-to-Edge Display
or Replacing the Display Assembly).
9. Replace the secondary hard drive (see Replacing the Secondary Hard Drive (HDD2)
).
10. Replace the base assembly cover (see Replacing the Base Assembly Cover
).
11. Follow the procedures in After Working on Your Computer
.
