Dell S3423DWC User Manual

Operating your monitor │ 43
Icon Menu and
Submenus
Description
USB
Selection
Allows you to assign the USB upstream port for the
input signals (HDMI 1 and HDMI 2), so that the moni-
tor’s USB downstream port (for example, keyboard and
mouse) can be used by the current input signals when
you connect a computer to either one of the upstream
ports. See also Setting the KVM switch for details.
When you use only one upstream port, the connected
upstream port is active.
Display
Brightness / Contrast
Dell 34 Monitor
Input Source
Color
Menu
Audio
Menu
Others
Others
PersonalizePersonalize
Audio
USB-B
USB-C
PIP/PBP
USB Selection
HDMI 1
HDMI 2
NOTE: To prevent data damage or loss,
before changing USB upstream ports, make
sure that NO USB storage devices are in use
by the computer connected to the monitor’s
USB downstream port.
Audio Change the audio settings.
Display
Brightness / Contrast
Dell 34 Monitor
Input Source
Color
MenuMenu
Others
Others
PersonalizePersonalize
AudioAudio
PIP/PBP
USB Selection
Volume
Speaker
Reset Audio
Enable
50
Volume Presses the buttons to adjust the volume. Minimum is
‘0’ (-). Maximum is ‘100’ (+).
Speaker Selects this option to activate the speaker.
Reset Audio Selects this option to restore default display settings.

Dell S3423DWC Specifications

General

Panel type	VA
Color gamut	99 %
Pixel pitch	0.2318 x 0.2318 mm
Pixel density	109 ppi
Backlight type	LED
Display diagonal	34 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	21:9
Response time (fast)	5 ms
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Viewable size diagonal	864.2 mm
Viewable size, vertical	333.7 mm
Display number of colors	16.7 million colors
Display diagonal (metric)	86.42 cm
Viewable size, horizontal	797.2 mm
Digital vertical frequency	48 - 100 Hz
Digital horizontal frequency	30 - 160 kHz
Display brightness (typical)	350 cd/m²
High Dynamic Range (HDR) supported	No
AMD FreeSync type	FreeSync
RMS rated power	10 W
Number of speakers	2
USB upstream port type	USB Type-B, USB Type-C
USB Power Delivery up to	65 W
USB Type-C downstream ports quantity	0
Number of USB Type-B upstream ports quantity	1
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	160 W
Power consumption (off)	0.3 W
Power consumption (standby)	0.4 W
Power consumption (typical)	31 W
Package depth	942.34 mm
Package width	223.52 mm
Package height	449.58 mm
Package weight	15210 g
Doesn't contain	PVC/BFR
Sustainability certificates	RoHS
Feet color	Silver
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Cables included	AC, USB Type-A, USB Type-C to USB Type-C
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	8.64 mm
Bezel width (side)	8.65 mm
Depth (with stand)	217.05 mm
Width (with stand)	808.16 mm
Height (with stand)	489.36 mm
Weight (with stand)	9740 g
Bezel width (bottom)	22.14 mm
Depth (without stand)	64.03 mm
Height (without stand)	364.5 mm
Weight (without stand)	6650 g
