Dell S3423DWC User Manual

44 │ Operating your monitor
Icon Menu and
Submenus
Description
Menu Selects this option to adjust the settings of the OSD,
such as the languages of the OSD, the amount of time
the menu remains on screen, and so on.
Display
Dell 34 Monitor
Input Source
Color
Audio
Others
Others
PersonalizePersonalize
Audio
PIP/PBP
USB Selection
Menu
Brightness / Contrast
Language
Transparency 20
Timer
Lock
English
20 s
Reset Menu
Disable
Language Set the language option for the OSD display: English,
Spanish, French, German, Brazilian Portuguese,
Russian, Simplified Chinese, or Japanese.
Transpar-
ency
Presses the or button to change the menu
transparency (0 to 100).
Timer OSD hold time: sets the length of time the OSD will
remain active after the last time you pressed a button.
Presses the or button to adjust the slider in 1
second increments, from 5 to 60 seconds.
Lock Controls user access to adjustments. User can select
one of the following: Menu Buttons, Power Button,
Menu + Power Buttons, Disable.
Reset Menu Resets all OSD settings to the factory preset values.

Dell S3423DWC Specifications

General

Panel type	VA
Color gamut	99 %
Pixel pitch	0.2318 x 0.2318 mm
Pixel density	109 ppi
Backlight type	LED
Display diagonal	34 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	21:9
Response time (fast)	5 ms
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Viewable size diagonal	864.2 mm
Viewable size, vertical	333.7 mm
Display number of colors	16.7 million colors
Display diagonal (metric)	86.42 cm
Viewable size, horizontal	797.2 mm
Digital vertical frequency	48 - 100 Hz
Digital horizontal frequency	30 - 160 kHz
Display brightness (typical)	350 cd/m²
High Dynamic Range (HDR) supported	No
AMD FreeSync type	FreeSync
RMS rated power	10 W
Number of speakers	2
USB upstream port type	USB Type-B, USB Type-C
USB Power Delivery up to	65 W
USB Type-C downstream ports quantity	0
Number of USB Type-B upstream ports quantity	1
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	160 W
Power consumption (off)	0.3 W
Power consumption (standby)	0.4 W
Power consumption (typical)	31 W
Package depth	942.34 mm
Package width	223.52 mm
Package height	449.58 mm
Package weight	15210 g
Doesn't contain	PVC/BFR
Sustainability certificates	RoHS
Feet color	Silver
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Cables included	AC, USB Type-A, USB Type-C to USB Type-C
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	8.64 mm
Bezel width (side)	8.65 mm
Depth (with stand)	217.05 mm
Width (with stand)	808.16 mm
Height (with stand)	489.36 mm
Weight (with stand)	9740 g
Bezel width (bottom)	22.14 mm
Depth (without stand)	64.03 mm
Height (without stand)	364.5 mm
Weight (without stand)	6650 g
