Dell Vostro 3591 - Installing the System Fan

Installing the system fan
Steps
1. Align the screw holes on the fan with the screw holes on the palm rest and keyboard board assembly [1].
2. Replace the three (M2.5x5) screws that secure the fan to the palm rest and keyboard board assembly [2].
34
Removing and installing components
