Next steps
1. Replace the battery
2. Replace the base cover
3. Replace the optical drive assembly
4. Replace the SD memory card
5. Follow the procedure in after working inside your computer
Display assembly
Removing the display assembly
Prerequisites
1. Follow the procedure in before working inside your computer
2. Remove the SD memory card
3. Remove the optical drive assembly
4. Remove the base cover
5. Disconnect the battery cable from the connector on the system board
6. Remove the WLAN
Steps
1. Open the latch and disconnect the optical drive cable and display cable from the system board [1, 2].
2. Peel off the tape securing the wireless antenna from the system board [3].
3. Unroute the display cable from the routing guides on the palmrest and keyboard assembly [4].
48
Removing and installing components
