Dell Vostro 3591 - Installing the Heatsink

Installing the heatsink
Steps
1. Place the heatsink on the system board and align the screw holes on the heatsink with the screw holes on the system board [1].
2. Replace the three (M2x3) screws that secure the heatsink to the system board [2].
3. In sequential order (as indicated on the heatsink), tighten the four captive screws that secure the heatsink to the system board [3].
