Steps
Place the palm-rest and keyboard assembly on a flat surface.
Next steps
1. Install the touchpad.
2. Install the power-adapter port.
3. Install the display assembly.
4. Install the system board.
5. Install the speakers.
6. Install the 4-cell battery or the 3-cell battery.
7. Install the base cover.
8. Follow the procedure in After working inside your computer.
Power button with fingerprint reader
Removing the power button with fingerprint reader
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the 4-cell battery or the 3-cell battery.
4. Remove the speakers.
5. Remove the system board.
NOTE: The system board can be removed with the heat sink attached.
6. Remove the display assembly.
7. Remove the power-adapter port.
About this task
The following image indicates the location of power-adapter port and provides a visual representation of the removal procedure.
46
Disassembly and reassembly
