Steps
1. Peel off the mylar tape that secures the power button with fingerprint reader cable connection.
2. Disconnect the power button with fingerprint reader cable from the connector on the palm-rest and keyboard assembly.
3. Lift the power button with fingerprint reader off the palm-rest and keyboard assembly.
Installing the power button with fingerprint reader
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image indicates the location of power-adapter port and provides a visual representation of the installation
procedure.
Disassembly and reassembly
47
