Dell XPS 14 - Removing the Base Cover

12 | Removing the Base Cover
Removing the Base Cover
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 9. After working inside your computer, follow the instructions in
"After Working Inside Your Computer" on page 11. For additional safety best
practices information, see the Regulatory Compliance Homepage at
dell.com/regulatory_compliance.
Procedure
1 Close the display, and turn the computer over.
2 Place your fingertip at the indicator on the base-cover assembly.
3 Turn the system badge over and place it on the base-cover assembly.
4 Remove the screws under the system badge that secure the base-cover assembly.
1 system badge 2 base-cover assembly
1
2
