64 | Removing the Keyboard
Procedure
CAUTION: The keycaps on the keyboard are fragile, easily dislodged, and
time-consuming to replace. Be careful when removing and handling the
keyboard.
1 Note the location of the mylars and peel them from the keyboard bracket.
2 Remove the screws that secure the keyboard bracket to the palm-rest assembly.
1mylars (3)
book.book Page 64 Wednesday, June 20, 2012 2:23 PM
