Removing the Palm Rest
|
69
Procedure
1
Remove the screws that secure the palm rest to the display hinges.
2
Open the palm rest as far as possible.
1
screws (6)
2
disp
lay hinges (2)
3p
a
l
m
r
e
s
t
1
3
2
book
.boo
