Technical data
3 Technical data
Note: Detailed dimensions are found in the dimension drawing in the appendix,
chapter 11.2 Dimensions, page 32.
3.1 Display unit
Dimensions L x W x H
approx. 145 x 63 x 31 mm
Weight
161 g
Display range
0.1 – 99,999 mW/cm²
Resolution of the UV irradiance
0.1 mW/cm²
Operating temperature
+5 °C to +40 °C
Voltage supply
2 x mignon AA 1.5 V
Interface
USB
3.2 Detector head
Dimensions
dia. 37 x 8 mm
Weight
100 g
Diameter of the detection area
9 mm (UVA, BLUE, LED 9 mm)
1 mm (LED 1 mm)
Operating temperature
+5 °C to +100 °C
Calibration
irradiance in mW/cm² with
factory calibration report
Connection line
light guide, length: 1.3 m
minimum bending radius: 100 mm
Irradiation time
interval / no permanent irradiation
3.3 Sensor types
Sensor Wavelength range
UVA sensor
315 – 395 nm*
BLUE sensor
390 – 480 nm*
9 mm LED sensor
365 / 400 / 460 nm
1 mm LED sensor
365 / 400 / 460 nm
* The calibration standard is a Hg bulb. The reference basis is the spectrum of DELOLUX 03 S and DELOLUX 04
