26
Operation
7.2.4 Measuring with adapter
When controlling intensity values, for example, at the light guide exit, an adapter must
be used. Furthermore, the adapter selection in the parameter set of the display unit must
be selected. This ensures adjustment and centering of the light guide. In addition, the
detection area is reduced accordingly when selecting the adapter size in the parameter
set.
Exception are LED sensors. The enclosed adapters do not reduce the respective sensor
area. Therefore, only the wavelength range must be selected when using LED sensors.
Example: UVA head with 3 mm adapter:
UVA Apt 3 mm
SN: 12482
4500.2
7.2.5 Limiting value Emin
In special cases, it must be visually displayed in the scope of process monitoring if the
intensity value measured is underrun. An intensity value in mW/cm² can be set in the
menu point „Emin“ by means of the arrow key. If the specifi ed value is underrun, the
display starts blinking. If the value is overrun, the value is permanently displayed. If the
Emin function is to be suppressed, the limiting value must be reduced to zero. When
delivered, the device has a limiting value of 1000 mW/cm².
1000
Emin
7.2.6 USB interface
DELOLUXcontrol has a USB interface as standard. With it, the current measuring data can
be transferred to another system (e. g., PLC or PC). The necessary DLL data are stored on
the CD-ROM enclosed in the shipment. In addition, the CD-ROM includes an example
software (created in LabVIEW Vers. 8.20) to visualize the measuring values.
