Operation
7.2.2 Menu navigation
After initialization of DELOLUXcontrol, the basic view/start screen is displayed. The sensor
selection depends on the last selected detector head. The current measuring value, the
detector head type incl. serial number as well as the selected adapter (in case of UVA or
BLUE) resp. the wavelength (LED detector head) are displayed.
When interchanging a detector head, the head is to be selected according to the above
menu structure. The sensor is not automatically recognized when it is plugged into the
display unit.
Every key is occupied with a dual function.
Key Description Functions / modes
menu / enter:
Mode 1 – Measuring view
Starting point: Switched off device or start screen
The device is switched on or off. When switching off, the
key must be pressed for a certain period of time (approx. 2 s)
until the display goes out.
Mode 2 – Confi guration view
Starting point: Submenu of start screen
Another function of this key is the confi rmation of the menu
selection or the parameter setting, or the navigation
to the submenu.
Further menu points as well as sensor, adapter size or wavelength are selected by the
arrow keys:
Key Description Functions / modes
run / stop
Mode 1 – Measuring view
Starting point: Start screen
With this key, the displayed value can be kept (Hold). The
current measuring value is frozen. The value display is
activated again (RUN) by pressing the key again.
Mode 2 – Confi guration view
Starting point: Submenu (e. g., detector selection)
The key arrow is activated in the submenu. That means that
it is possible to navigate between the menu points. With this
key, you can navigate upwards.
