Design and function
4 Design and function
DELOLUXcontrol, in combination with the corresponding detector heads, serves to
measure and control the intensity of the polymerization-effective radiation of a curing
lamp. The detector heads are subject to calibration. Comply with the manufacturer’s
instructions and operating instructions of the lamps to be measured/controlled under
any circumstances.
In combination with different detector heads, the intensity at the required working position
can be measured. Alternatively, the intensity at the light guide outlet or the lamp head can
be detected. In order to measure the intensity directly at the light guide outlet or the lamp
head of a DELOLUX lamp, an adapter ( aperture) must be screwed on / attached for
centering.
Application areas:
Sensor Wavelength range in combination with
UVA sensor
315 – 395 nm* DELOLUX 03 S
DELOLUX 04 (with adapter if required)
DELOLUX 06
BLUE sensor
390 – 480 nm* DELOLUX 03 S
DELOLUX 04 (with adapter if required)
DELOLUX 06
9 mm LED sensor
365 / 400 / 460 nm DELOLUX 20
DELOLUX 202
DELOLUX 22
DELOLUX 80 (with adapter if required)
1 mm LED sensor
365 / 400 / 460 nm DELOLUX 50 (with adapter if required)
* The calibration standard is a Hg bulb. The reference basis is the spectrum of DELOLUX 03 S and DELOLUX 04
