Installation and connection
6 Installation and connection
6.1 Safety instructions
CAUTION!
Damage or faulty measuring results through improper installation
and connection!
Therefore:
 Do not position the detector head in such a way that it is permanently
in the ray path.
 Do not bend the metal sheathing of the detector head line (minimum
bending radius 100 mm).
 Do not subject the signal line to torsional or tensile stress.
 Pay attention to the permissible ambient temperatures.
 Prevent radiation from other light sources and solar radiation.
 Protect the device from humidity.
 Follow the safety instructions and operating instruction of the
irradiation equipment used.
 Pay attention to the specifi c allocation of detector to DELOLUXcontrol.
Personal protective equipment
Wear protective clothing when operating the module:
 Protective clothes
 Safety glasses
 Protective gloves
6.2 Installation and connection
DELOLUXcontrol is designed for mobile use.
NOTE!
Store the light intensity meter in the supplied hard top case for optimal
protection.
Only the detector heads assigned to DELOLUXcontrol can be used as the calibration data
of the detector heads are saved in the calibration data memory of the light intensity meter.
The detector heads are assigned via the corresponding serial numbers that are found on
the back of the device, on the cylindric part of the sensor, as well as in the supplied
factory calibration report.
Start of operation
Attach the detector head to the miniature SUB-D. Secure the plug against unintended
unplugging by means of the locking screws. Switch on the device and select the sensor,
the adapter if applicable and/or the wavelength (see chapter 7 Operation, page 22). The
device is switched off by pressing the menu / enter key over a certain period of time
(approx. 2 s).
