Design and function
4.1 Device overview
4.1.1 Display unit
1
2
Pos. Control element /
component
Remark
1
LCD display The display indicates the currently measured value in
mW/cm². (Exception: Display UL/ OL = measuring
value to high resp. too low)
In addition, the display shows the serial number of
the selected detector head, the selected adapter
( aperture reduction of the measuring area) if
applicable, or the specifi c wavelength (LED
detector heads).
2
Control panel Panel for startup of DELOLUX control, menu
navigation, display background lighting, measuring
value hold function, switching off.
