25
Operation
Key Description Functions / modes
light
Mode 1 – Measuring view
Starting point: Start screen
The display background lighting can be switched on and off.
Mode 2 – Confi guration view
Starting point: Submenu (e. g., detector selection)
The key arrow is activated in the submenu. That means that
it is possible to navigate between the menu points. With this
key, you can navigate downwards.
7.2.3 Measuring without adapter
To determine the intensity at an irradiated area of d 9 mm, the setting „no Apt (9 mm)“
must be selected. In this case, the complete sensor area (d = 9 mm) is considered for
displaying the intensity value. This setting is normally used when controlling area lamps
(e. g., DELOLUX 03 S, DELOLUX 20), or when measuring in the working position, provided
that the radiation source illuminates the sensor area.
Example: UVA head without adapter:
UVA no Apt (9 mm)
SN: 12482
75.5
