Owner´s Manual DEA600 Radio
17 |
P a g e
• MS-Dos partition only.
• Class specification (USB MSC) and supports formats o
f FAT32,
FAT16, NTFS, and HFS+.
• Hard disk drives may be played, but they are not sup
ported.
• The radio will not be able to play back write-protec
ted music.
• MTP players are not supported.
The following guidelines must be met when creating MP3 files; otherwise the
files might not play:
For MP3 Files
• Bit rates: 32, 40, 48, 56, 64, 80, 96, 112, 124, 160, 192, 224, 256,
320 kbps for MPEG-1 Audio Layer 3.
• Sampling frequencies: 32, 44.1 and 48 kHz for MPEG-1 Audio
Layer 3.
• Maximum number of folders: Eight folders with 255 files per folder.
• Maximum of 1,000 files on a disc.
• M3u and pls playlist versions supported.
• Recorded on a CD-R or CD-RW with a maximum capacity of 700
MB.
For Unprotected WMA Files
• Versions: 1, 2, 7, 8, 9 and 9.1.
• Bit rates: 32 - 320 kbps.
• Sampling frequencies: 32 - 48 kHz.
Error Messages
If an “UNSUPPORTED” message is displayed, it could b
e for one of the
following reasons:
• When a MTP Player or a USB device with unsupported format or
partition is connected.
• When the device is damaged.
• When the connected device was not connected as mass storage
device.
If “NO MUSIC” message is displayed, it could be because there are not MP3
or unprotected WMA files that can be played.
iPod
This Radio supports the following iPod models:
• iPod classic
®
(6th generation)
• iPod nano
®
( 6G)
• iPod touch
®
(4G)
• iPhone
®
(3G, 3GS, 4, and 4S)
Other iPods may be played, but functionality is not
guaranteed.
Radio provides up to 1A of charge, so any device connected to the USB that
requires less than 1 A will be charged.
There may be problems with the operation and function in the following
situations:
• When connecting an iPod on which a more recent version of the
firmware is installed than is supported by the Radio.
• When connecting an iPod with firmware from other providers is
installed.
Playing from an iPod
To connect an iPod:
1. Connect one end of the standard iPod USB cable to the iPod's dock
connector.
2. Connect the other end to the USB port in the front of Radio.
3. Radio will start playing the USB and shows the track number, Song,
Artist, elapsed time, and Album information when available.
4. If the iPod is an unsupported model, it can still be
listened to in the
vehicle by connecting to the auxiliary input jack using a standard
3.5 mm (1/8 in) stereo cable
5. To control and browse the selected media source refer to sections
Media Sources and Media Audio Control Soft key for further
information.
Expected behavior when iPod is connected:
• The iPod battery recharges automatically while the vehicle is on.
• The iPod shuts off and stops charging when the vehicle is shut off.
