Delphi DEA600 User Manual

Owner´s Manual DEA600 Radio
57 |
P a g e
Figure 118: The Manual equalizer screen.
The system adjusts the Bass value accordingly with t
he selected value in the
Bass bar control.
The system adjusts the Middle value accordingly with the selected value in
the Middle bar control.
The system adjusts the Treble value accordingly with the selected value in
the Treble bar control.
The scale of the Bars is from -12dB to +12dB.
The system supports detection of 24 steps on each of the bars.
The system adjusts 2 dB per step of the corresponding value.
Auto Equalization
In the case the Auto Equalization option is selected
, the system displays the
next options, see Figure 119 & Figure 120 as reference:
• POP
• ROCK
• COUNTRY
• NEWS
• JAZZ
• CLASSICAL
Figure 119: The Auto equalizer screen Part I.
Figure 120: The Auto equalizer screen Part II.

Delphi DEA600 Specifications

General

Brand	Delphi
Model	DEA600
Category	Car Receiver
Language	English
