Owner´s Manual DEA600 Radio
58 |
P a g e
Each Audio setting section has a checkbox as a selec
tor control. The system
adjusts the Audio output configuration based on the option selected. The
system does not allow selecting more than one Auto Equalization option.
In the case the system detects the selection of the current Auto Equalization
option, no change will take place.
Speed Dependent Volume
This function changes the volume level proportionall
y with the vehicle speed
in order to compensate for engine or road noise.
In the case the Speed Dependent Volume option is selected, the system
displays the next configurable options, see Figure 121 as reference:
• Off
• Low
• Mid
• High
Figure 121: The System audio screen Part II.
The system allows the selection of one option at a t
ime.
Speakers Configuration
In the case the Speakers configuration option is sel
ected, the system
displays the next configurable options, see Figure 121 as reference:
• 4 Speakers
• 2 Speakers
T
he system allows the selection of one option at a time.
Seek Sensitivity -6dB to +6dB
The seek sensitivity option is present in a bar selector manner.
The scale of the seek sensitivity Bar is from -6 dB to +6 dB. The system
detects 12 steps on each of the bars. The system adjusts 1 dB per step of
the corresponding value. As illustrated in Figure 122.
Figure 122: Seek sensitivity screen.
