Owner´s Manual DEA600 Radio
20 |
P a g e
If the Navigation audio is deactivated, then the rad
io shall switch to the last
source (if available) if not, the radio shall return to the last tuner mode.
Wi-Fi Media Playback
The DEA600 use DLNA for Media Playback using the Pus
h-Type
architecture; do not allowing control of the playback using the DEA600.
The DEA600 Smart Display behaves as a Digital Media Render with an
interface to allow the display of metadata content.
The DEA600 Smart Display support Wi-Fi Client / Wi-Fi AP / Wi-Fi Direct
features.
Radio Sources
The system displays the 4 Radio sources into the nex
t to the right
subsequent tab-bar as illustrated on Figure 31:
• AM
• FM
• Sirius XM
• WX
Figure 31: Audio App Tuner Sources.
There are 6 presets for WX, 12 presets for FM, 12 pr
esets for AM and 18
presets for SXM. 6 presets will be shown on each screen. Additional presets
can be viewed by swiping the preset bar. Each preset work as soft key
button selector. The presets that do not have a frequency assigned display
only the number of the grid.
In order to save a station in to a memory:
• Tune to the desired station.
• Press and hold one of the 6 presets
• When the selected station is displayed on the preset
, the station
has been saved in the selected preset.
The system displays the current tuned frequency along with the
corresponding radio Band.
The systems display a specific screen interface for the SiriusXM source.
AM/FM
The system presents the next control soft keys as part of the AM/FM radio
source interface:
• Next
• Previous
• Scan
• Strong Station list
• Update List
T
he AM/FM radio sources screens follow the distribution and styling Figure
31 illustrates.
WX
The WX band is for Governmental weather radio services frequencies; the
radio can tune 7 weather channels.
The system presents the next control soft keys as part of the WX radio
source interface:
• Next
To Next Page
