FEATURES
36-5000 T2 and 36-5100 T2
THESE CONTENTS IN
SEPARATE CARTON:
Rear Rail
Fence Guide
Front Fence Rail
(behind F20)
Table Saw
Extension Wing (3)
Switch Box
Tubular Stand
Fixed Wheels (2)
Adjustable Feet (2)
Pivoting Pedal and Caster
(attached to saw)
Lock Knobs (2)
Handwheel Handles (2)
(attached to saw)
Miter Gauge
Rip Fence Handle
Rip Fence
Throat Plate
Blade Guard
Anti-Kickback Pawls
Blade (attached to saw)
Push Stick
Fence Storage Mount
F9
F8
F19
F18
F10
F10
F11
F11
F12
F13
F12
F14
F13
F15
F14
F16
F16
F15
F17
F17
F19
F18
F20
F21
F20
F5
F5
F6
F6
F7
F7
F8
F9
F1
F1
F2
F2
F3
F3
F4
F4
NOTE: 36-5000 T2 has three Steel Extension Wings and 36-5100 T2 has two Cast Iron Extension Wings and one Steel Extension Wing.
