11.6.2 400 V Series
Motor Frame Size: 80 mm and below Models (Units: mm)
Model
J△0604□S
J△0807□S
J△0907□S
J△0910□S
LC
60
80
86
86
LZ
5.5
6.6
6.6
6.6
LA
70
90
100
100
S
)
(
.
19
0
0130


)
(16
0
011.0


)
(16
0
011.0


LB
)
(
.
70
0
0300


)
(80
0
030.0


)
(80
0
030.0


LL (without brake)
130.7
138.3
130.2
153.2
LL (with brake)
166.8
178.0
161.3
184.3
LS
27
32
30
30
LR
30
35
35
35
LE
3
3
3
3
LG
7.5
8
8
8
LW
20
25
20
20
RH
11
15.5
13
13
WK
5
6
5
5
W
5
6
5
5
T
5
6
5
5
TP
M4
Depth15
M6
Depth 20
M5
Depth 15
M5
Depth 15
NOTE
1) Dimensions are in millimeters. Actual measured values are in metric units.
2) Dimensions of the servo motor may be revised without prior notice.
3) The boxes () in the model names represent shaft end/brake or the number of oil seal.
4) Please refer to Chapter 1 for the boxes (△ ) in the model names (which represents encoder type).
