ASDA-A2 Chapter 12 Absolute System
12-4 Revision February, 2017
12.1.2 Battery Box Dimensions
Single Battery Box
Delta Model Number: ASD-MDBT0100
Units: mm
Weight
44 g
Dual Battery Box
Delta Model Number: ASD-MDBT0200
Units: mm
Weight
80 g
