Delta ASD-A2 Series

ASDA-A2 Chapter 11 Specifications
11-52 Revision February, 2017
Motor Frame Size: 180 mm and above Models (Units: mm)
Model
L△1830□S
L△1845□S
L△1855□S
L△1875□S
K△1820□S
LC
180
180
180
180
180
LZ
13.5
13.5
13.5
13.5
13.5
LA
200
200
200
200
200
S
)
(
.
35
0
0160


)
(
.
35
0
0160


)
(
.
42
0
0160


)
(
.
42
0
0160


)
(
.
35
0
0160


LB
)
(.
.
3114
0
0350


)
(.
.
3114
0
0350


)
(.
.
3114
0
0350


)
(.
.
3114
0
0350


)
(.
.
3114
0
0350


LL (without brake)
202.1
235.3
279.7
342.0
169.0
LL (with brake)
235.3
279.3
311.7
376.1
203.1
LS
73
73
108.5
108.5
73
LR
79
79
113
113
79
LE
4
4
4
4
4
LG
20
20
20
20
20
LW
63
63
90
90
63
RH
30
30
37
37
30
WK
10
10
12
12
10
W
10
10
12
12
10
T
8
8
8
8
8
TP
M12
Depth 25
M12
Depth 25
M16
Depth 32
M16
Depth 32
M12
Depth 25
NOTE
1) Dimensions are in millimeters. Actual measured values are in metric units.
2) Dimensions of the servo motor may be revised without prior notice.
3) The boxes () in the model names represent shaft end/brake or the number.
4) Please refer to Chapter 1 for the boxes (△ ) in the model names (which represents encoder type).
