Delta ASD-A2 Series User Manual

ASDA-A2 Appendix A Accessories
Revision February, 2017 A-25
3kW Servo Drive and 3kW Medium-High Inertia Servo Motor
Servo Drive ASD-A2-3023-
Medium-High Inertia Servo Motor
ECMA-F△1830S
Motor Power Cable (Without Brake) ASD-CAPW200X
Motor Power Cable (With Brake) ASD-CAPW210X
Power Connector ASD-CAPW2000
Incremental Type Encoder Cable ASD-CAEN100X
Absolute Type Encoder Cable ASD-A2EB100X
Encoder Connector ASD-CAEN1000
(X=3 indicates that the cable length is 3m; X=5 indicates that the cable length is 5m)
4.5kW Servo Drive and 4.5kW Medium-High Inertia Servo Motor
Servo Drive ASD-A2-4523-
Medium-High Inertia Servo Motor
ECMA-F△1845S
Motor Power Cable (Without Brake) ASD-CAPW320X
Motor Power Cable (With Brake) ASD-CAPW330X
Power Connector ASD-CAPW2000
Incremental Type Encoder Cable ASD-CAEN100X
Absolute Type Encoder Cable ASD-A2EB100X
Encoder Connector ASD-CAEN1000
(X=3 indicates that the cable length is 3m; X=5 indicates that the cable length is 5m)
5.5kW Servo Drive and 5.5kW Medium-High Inertia Servo Motor
Servo Drive ASD-A2-5523-
Medium-High Inertia Servo Motor
ECMA-F△18553
Motor Power Cable (Without Brake) -
Motor Power Cable (With Brake) -
Power Connector ASD-CAPW4000
Brake Connector ASD-CNBR1000
Incremental Type Encoder Cable ASD-CAEN100X
Absolute Type Encoder Cable ASD-A2EB100X
Encoder Connector ASD-CAEN1000
(X=3 indicates that the cable length is 3m; X=5 indicates that the cable length is 5m)

Delta ASD-A2 Series Specifications

General

Control Mode	Position, Speed, Torque
Feedback	Incremental encoder, Absolute encoder
Rated Output Power	0.1 kW to 15 kW
Power Supply	200-230V AC
Communication Interface	RS-485, CANopen
Protection Features	Overload, Overvoltage, Overcurrent, Overheat
