ASDA-A2 Chapter 3 Wiring
Revision February, 2017 3-41
Symbol
DO
Code
Output Function PT PR S T Sz Tz
PT-
S
PT-
T
PR-
S
PR-
T
S-T
SDO_5 0x35
Output the status of
bit05 of P4-06
SDO_6 0x36
Output the status of
bit06 of P4-06
SDO_7 0x37
Output the status of
bit07 of P4-06
SDO_8 0x38
Output the status of
bit08 of P4-06
SDO_9 0x39
Output the status of
bit09 of P4-06
SDO_A 0x3A
Output the status of
bit10 of P4-06
SDO_B 0x3B
Output the status of
bit11 of P4-06
SDO_C 0x3C
Output the status of
bit12 of P4-06
SDO_D 0x3D
Output the status of
bit13 of P4-06
SDO_E 0x3E
Output the status of
bit14 of P4-06
SDO_F 0x3F
Output the status of
bit15 of P4-06
NOTE
Please refer to Section 3.4.1 for corresponding pin from DO1 to 5.
