Chapter 10 Specifications ASDA-B2
10-22
Revision May, 2018
Motor Frame Size: 100 mm ~ 130 mm Models (Units: mm)
Model
C△1010□ S
C△1020□ S
C△1330□
4
E△1305□
S
E△1310□ S
E△1315□
S
E△1320□ S
LC 100 100 130 130 130 130 130
LZ 9 9 9 9 9 9 9
LA 115 115 145 145 145 145 145
S
)
(
.
22
0
0130
+
−
)
(
.
22
0
0130
+
−
)
(24
0
013.0
+
−
)
(
.
22
0
0130
+
−
)
(
.
22
0
0130
+
−
)
(
.
22
0
0130
+
−
)
(
.
22
0
0130
+
−
LB
)
(
.
95
0
0350
+
−
)
(
.
95
0
0350
+
−
)
(110
0
035.0
+
−
)
(
.
110
0
0350
+
−
)
(
.
110
0
0350
+
−
)
(
.
110
0
0350
+
−
)
(
.
110
0
0350
+
−
LL
(without brake)
153.3 199 187.5 147.5 147.5 167.5 187.5
LL
(with brake)
192.5 226 216.0 183.5 183.5 202 216
LS 37 37 47 47 47 47 47
LR 45 45 55 55 55 55 55
LE 5 5 6 6 6 6 6
LG 12 12 11.5 11.5 11.5 11.5 11.5
LW 32 32 36 36 36 36 36
RH 18 18 20 18 18 18 18
WK 8 8 8 8 8 8 8
W 8 8 8 8 8 8 8
T 7 7 7 7 7 7 7
TP
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
(1) Dimensions are in millimeters.
(2) Dimensions and weights of the servo motor may be revised without
prior notice.
(3) The boxes () in the model names represent shaft end / brake or the
number of oil seal.
(4) Please refer to Chapter 1 for the boxes (△) in the model names
(which represents encoder type).
