Delta ASD-B2-0121-B

ASDA-B2 Chapter 10 Specifications
Revision May, 2018 10-23
Motor Frame Size: 100 mm ~ 130 mm Models (Units: mm)
Model
F△1308□ S F△1313□ S F△1318□ S G△1303□ S G△1306□ S G△1309□ S
LC 130 130 130 130 130 130
LZ 9 9 9 9 9 9
LA 145 145 145 145 145 145
S
)
(
.
22
0
0130
+
−
)
(
.
22
0
0130
+
−
)
(
.
22
0
0130
+
−
)
(
.
22
0
0130
+
−
)
(
.
22
0
0130
+
−
)
(
.
22
0
0130
+
−
LB
)
(
.
110
0
0350
+
−
)
(
.
110
0
0350
+
−
)
(
.
110
0
0350
+
−
)
(
.
110
0
0350
+
−
)
(
.
110
0
0350
+
−
)
(
.
110
0
0350
+
−
LL
(without brake)
152.5 187.5 202 147.5 147.5 163.5
LL
(with brake)
181 -- -- 183.5 183.5 198
LS 47 47 47 47 47 47
LR 55 55 55 55 55 55
LE 6 6 6 6 6 6
LG 11.5 11.5 11.5 11.5 11.5 11.5
LW 36 36 36 36 36 36
RH 18 18 18 18 18 18
WK 8 8 8 8 8 8
W 8 8 8 8 8 8
T 7 7 7 7 7 7
TP
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
(1) Dimensions are in millimeters.
(2) Dimensions and weights of the servo motor may be revised without
prior notice.
(3) The boxes () in the model names represent shaft end / brake or the
number of oil seal.
(4) Please refer to Chapter 1 for the boxes (△) in the model names
(which represents encoder type).
NOTE
