Delta DVP-ES2 Manual

3 Mixed Analog Input/Output Module DVP06XA-E2
2. Default setting = K0.
CR#32, 33: Adjusted Offset value of CH5 ~ CH6
[Explanation]
1. Set the adjusted Offset value of CH5 ~ CH6, which represents the voltage (current) output value
corresponds to digital value 0
2. Default setting = K0.
CR#34, 35, 36, 37: Adjusted Gain value of CH1 ~ CH4
[Explanation]
1. Set the adjusted Gain value of CH1 ~ CH4, which represents the voltage (current) input value
corresponds to digital value 16,000.
2. Default setting = K16,000.
CR#38, 39: Adjusted Gain value of CH5 ~ CH6
[Explanation]
1. Set the adjusted Gain value of CH5 ~ CH6, which represents the voltage (current) output value
corresponds to digital value 16,000.
2. Default setting = K16,000.
CR#40: Function: Set value changing prohibited, Default = H’0000
[Explanation]
Description
bit0 b0=0, CH1 changing allowed; b0=1, CH1 changing prohibited
bit1 b1=0, CH2 changing allowed; b1=1, CH2 changing prohibited
bit2 b2=0, CH3 changing allowed; b2=1, CH3 changing prohibited
bit3 b3=0, CH4 changing allowed; b3=1, CH4 changing prohibited
bit4 b4=0, CH5 changing allowed; b4=1, CH5 changing prohibited
bit5 b5=0, CH6 changing allowed; b5=1, CH6 changing prohibited
bit6 ~ bit15 Reserved
Relative Parameters
CR#2 ~ CR#5 Input mode setting at CH1 ~ CH4
CR#6 ~ CR#7 Output mode setting at CH5 ~ CH6
CR#8 ~ CR#11 Average times of CH1 ~ CH4
CR#28 ~ CR#33 Adjusted Offset value of CH1 ~ CH6
CR#34 ~ CR#39 Adjusted Gain value of CH1 ~ CH6
CR#42 Return to default setting
CR#100 Function: Enable/Disable limit detection
CR#102~CR#107 Set value of CH1~CH6 upper bound
CR#108~CR#113 Set value of CH1~CH6 lower bound
CR#114~CR#115 Output update time of CH5~ CH6
CR#118 LV output mode setting of Ch5 ~ Ch6
CR#41: Function: Save all the set values. Default=H’0000
[Explanation]
Save function setting. Save all the set values to the internal flash memory. When saving is completed,
CR#41 will be set to H’FFFF.
Set value Function
H0 No action
HFFFF Saving completed
H5678 Saving enabled.
Note: Default setting = H0. When set value = H’5678, saving will be enabled, and CR#41 will be set to
H’FFFF when saving is completed. If the set value is not H’5678, the set value will remain H’0. For
example, input K1 into CR#41, and the value will remain H’0.
DVP-ES2 Module Manual
3-8
