Delta DVP-ES2

4 Temperature Measurement Module DVP 04PT-E2
CR#42: Function: Return to default setting, Default = H’0000
[Explanation]
Description
bit0 b0=0, no action on CH1; b0=1, set CH1 to default setting
bit1 b1=0, no action on CH2; b1=1, set CH2 to default setting
bit2 b2=0, no action on CH3; b2=1, set CH3 to default setting
bit3 b3=0, no action on CH4; b3=1, set CH4 to default setting
bit4 ~ bit15 Reserved
Note: Set designated bit as 1 and the corresponding channel will be returned to default setting. When
setting is completed, the value will be set to 0. If CR#40(Set value changing prohibited) is enabled, the
default setting in CR#42 will be invalid, and all set values will remain unchanged. Error Code bit 12 of
CR#43 will be set to 1
Relative Parameters
CR#2 ~ CR#5 Input mode setting at CH1 ~ CH4
CR#8 ~ CR#11 Average times at CH1 ~ CH4
CR#28 ~ CR#31 Offset settings at CH1 ~ CH4
CR#100 Function: Enable/Disable limit detection
CR#102~CR#105 Set value of CH1~CH4 upper bound
CR#108~CR#111 Set value of CH1~CH4 lower bound
CR#120~CR#196 PID relative settings
CR#43: Error status. Default=H’0000
[Explanation]
CR#43: error status value. See the table below:
Description
bit0 K1 (H’1) Power Supply error
bit1 K2 (H’2) Hardware error
bit2 K4 (H’4) Upper / lower limit error
bit3 K8 (H’8) CH1 Conversion error
bit4 K16 (H’10) CH2 Conversion error
bit5 K32 (H’20) CH3 Conversion error
bit6 K64 (H’40) CH4 Conversion error
bit7 ~ bit8 Reserved
bit9 K512(H’0200) Mode setting error
bit10 K1024(H’0400) Average times error
bit11 K2048(H’0800) Upper / lower limit setting error
bit12 K4096(H’1000) Set value changing prohibited
bit13 K8192(H’2000) Communication breakdown on next module
bit14 ~ bit15 Reserved
Note: Each error status is determined by the corresponding bit (b0 ~ b13) and there may be more
than 2 errors occurring at the same time. 0 = normal; 1 = error
CR#100: Function: Enable/Disable limit detection. Default =H’0000
[Explanation]
Description
bit0=1 Enable CH1 limit detection
bit1=1 Enable CH2 limit detection
bit2=1 Enable CH3 limit detection
bit3=1 Enable CH4 limit detection
bit4 ~ bit15 Reserved
CR#101: Upper and lower bound status. Default =H’0000
[Explanation]
Description
bit0=1 CH1 exceeds lower bound
bit1=1 CH2 exceeds lower bound
bit2=1 CH3 exceeds lower bound
