CR#28, 29, 30, 31: Adjusted Offset value of CH1 ~ CH4
[Explanation]
1. Set the adjusted Offset value of CH1 ~ CH4.
2. Range: K-400~K400
3. .Default setting = K0
.
Definition of Offset at Ch1 ~ Ch4 in DVP04PT-E2:
Deviation digital value from the target temperature/voltage
Mode 0 ~ Mode 3:
Equation:











 Offset
X
Y
)( 1 . 0
)(
Y = digital output, X = measured input temperature
Mode 4:
Equation:








 Offset
X
Y
)Ohm(1.0
)Ohm(
Y = digital output, X = measured input impedance
CR#40: Function: Set value changing prohibited, Default = H’0000
[Explanation]
Description
bit0 b0=0, CH1 changing allowed; b0=1, CH1 changing prohibited
bit1 b1=0, CH2 changing allowed; b1=1, CH2 changing prohibited
bit2 b2=0, CH3 changing allowed; b2=1, CH3 changing prohibited
bit3 b3=0, CH4 changing allowed; b3=1, CH4 changing prohibited
bit4 ~ bit15 Reserved
Relative Parameters
CR#2 ~ CR#5 Input mode setting at CH1 ~ CH4
CR#8 ~ CR#11 Average times at CH1 ~ CH4
CR#28 ~ CR#31 Offset settings at CH1 ~ CH4
CR#42 Returning to default setting
CR#100 Function: Enable/Disable limit detection
CR#102~CR#105 Set value of CH1~CH4 upper bound
CR#108~CR#111 Set value of CH1~CH4 lower bound
CR#120~CR#196 PID relative settings
CR#41: Function: Save all the set values. Default=H’0000
[Explanation]
Save function setting. Save all the set values to the internal flash memory. When saving is completed,
CR#41 will be set to H’FFFF.
Set value Function
H0 No action
HFFFF Saving completed
H5678 Saving enabled.
Note: Default setting = H0. When set value = H’5678, saving will be enabled, and CR#41 will be set to
H’FFFF when saving is completed. If the set value is not H’5678, the set value will remain H’0. For
example, input K1 into CR#41, and the value will remain H’0.
