Appendix F General Specifications
F-5
F.4 TP Series - General Specifications
This specification is applicable to DVP-TP Series PLC CPU and their compatible extension
modules.
Item
Specifications
Operating temperature
0 to 55°C
Storage temperature
-20 to 60°C
Operating humidity
20–90% RH (No condensation)
Work environment
No corrosive gas exists.
Installation location
In a control box
Pollution degree
2
Ingress protection of
front panel (IP ratings)
IP66/NEMA4/UL Type4X (indoor use only)
Insulation voltage
Above 5MΩ
The voltage between all inputs/outputs and the ground is 500 VDC.
Noise Immunity
ESD (IEC 61131-2, IEC 61000-4-2): 8KV Air Discharge, 4KV
Contact Discharge
EFT (IEC 61131-2, IEC 61000-4-4): Power Line: 2KV, Digital I/O:
1KV, Analog & Communication I/O: 1KV
RS (IEC 61131-2, IEC 61000-4-3): 80MHz ~ 1GHz, 10V/m
Surge (IEC 61131-2, IEC 61000-4-5):
DC power: CM ±0.5 kV, DM ±0.5 kV,
Analog I/O, digital I/O, communication I/O: CM ±1 kV,
AC IO (Relay Output): CM ±2 kV, DM ±1 kV
Ground
The diameter of the ground should not be less than the diameters of
the cables connected to the terminals L and N.
It is required to use grounding if more than one PLC is being used
at the same time.
Vibration / Shock
resistance
Vibration: IEC 60068-2-6(test Fc), 1g DIN rail mount
Shock resistance: IEC 60068-2-27(test Ea), 15 g, 11 ms pulse, 6
shocks in each of 3 axes
Cooling Method
Natural air-cooling
