3.6.3 Four Arithmetic Operations
API
Mnemonic
PULSE Function
Applicable to STEPS
16 bits 32 bits
ES2
EX2
EC5
SS2
SA2
SE
SX2 16-bit 32-bit
20
ADD
DADD

Addition
   
7
13
21
SUB
DSUB

Subtraction
   
7
13
22
MUL
DMUL

Multiplication
   
7
13
23
DIV
DDIV

Division
   
7
13
24
INC
DINC

Increment
   
3
5
25
DEC
DDEC

Decrement
   
3
5
26
WAND
DAND

Logical Word AND
   
7
13
27
WOR
DOR

Logical Word OR
   
7
13
28
WXOR
DXOR

Logical XOR
   
7
13
29
NEG
DNEG

2’s Complement (Negation)




3
5
114
MUL16
MUL32

16-bit/32-bit Binary Multiplication
   
7
13
115
DIV16
DIV32

16-bit/32-bit Binary Division
   
7
13
