Appendix D Introducing the Current Consumption of Slim PLCs/Extension Modules
D-3
D.1.2 Current supply and current consumption of a digital input/output module (+24VDC)
Model
Internal maximum current
consumed by the IO-BUS (mA)
Maximum current consumed by
the external DIO (A)
06SN11R
82
36
08SM10N
40
0.08
08SM11N
15
0.05
08SN11R
55
5
08SN11T
55
1.2
08SN11TS
15
2
08SP11R
35
5
08SP11T
35
1.2
08SP11TS
15
1.25
08ST11N
55
0
16SM11N
25
0.1
16SN11T
65
1.2
16SN11TS
30
2
16SP11R
65
5
16SP11T
65
1.2
16SP11TS
30
2
32SM11N
40
0.16
32SN11TN
40
2
D.1.3 Current consumption of a special input/output module (+24VDC)
A special input/output module must be supplied with +24VDC power.
Model
Internal maximum current
consumed by the IO-BUS (mA)
Maximum current consumed by
the external DIO (A)
01PU-S 100 105
02DA-S 30 125
02TUL-S 75 40
02TUN-S 55 600
02TUR-S 60 600
04AD-S 30 83
04AD-S2 30 83
04DA-S 30 167
04DA-S2 30 167
04PT-S 30 83
04TC-S 30 83
06AD-S 30 83
06PT-S 83 -
06XA-S 30 83
06XA-S2 30 83
08NTC-S 30 -
