Delta DVP-EX2 - C.1 TP Memory Map

DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
A-2
C.1 TP Memory Map
Specifications
Control Method
Stored program, cyclic scan system
I/O Processing Method
Batch processing method (when END instruction is
executed)
Execution Speed
LD instructions – 0.54µs, MOV instructions – 3.4µs
Program language
Instruction List + Ladder + SFC
Program Capacity
TP70P-RM0: 2k, TP70P: 4k, TP04P: 8ksteps
Relay (Bit)
X
External inputs
X0~X7;X10~X17
(*4)
Y
External outputs
Y0~Y7;Y10~Y17
M
Auxiliar
y relay
General
M0~M511, 512 points max, (*1)
M768~M999, 232 points max, (*1)
M2000~M2047, 48 points max, (*1)
Total
4096 points
Latched
M512~M767, 256 points max, (*2)
M2048~M4095, 2048 points max, (*2)
Special
M1000~M1999, 1000 points, some
are latched
T Timer
100ms
(M1028=ON,
T64~T126:
10ms)
T0~T126, 127 points, (*1)
T128~T183, 56 points, (*1)
Total
251 points
T184~T199 for Subroutines, 16
points, (*1)
T250~T255 (accumulative), 6 points,
(*1)
10ms
(M1038=ON,
T200~T245:
1ms)
T200~T239, 40 points, (*1)
T240~T245 (accumulative), 6 points,
(*1)
Relay (Bit)
C Counter
16-bit count up
C0~C111, 112 points, (*1)
C128~C199, 72 points, (*1)
Total
140 points
C112~C127, 16 points, (*2)
32-bit count
up/down
C200~C223, 24 points, (*1)
C224~C232, 9 points, (*2)
C233~C234, 2 points, (*2)
C237~C250, 14 points, (*2)
C252~C255, 3 points, (*2)
32bit high-speed
count up/down
C235, C236 , 1 phase 1 input, 2
points (*2)
Total
3 points
C251, 2 phase 2 input, 1 point (*2)
Only available for twofold and fourfold
frequencies
S
Step
point
Initial step point S0~S9, 10 points, (*2)
Total
1024 points
Zero point return
S10~S19, 10 points (use with IST
instruction), (*2)
Latched
S20~S127, 108 points, (*2)
General
S128~S911, 784 points, (*1)
Alarm
S912~S1023, 112 points, (*2)
Word
Register
T
Current value
T0~T255, 256 words
C Current value
C0~C199, 16-bit counter, 200 words
C200~C254, 32-bit counter, 55 words
D
Data
register
General
D0~D407, 408 words, (*1)
D600~D999, 400 words, (*1)
D3920~D3999, 80 words, (*1)
Total
5000
Latched
D408~D599, 192 w
ords, (*2)
D2000~D3919, 1920 words, (*2)
