Delta DVP-EX2 - D.1.4 Current consumption of a left-side high-speed special module (+24 VDC); D.1.5 Calculating the maximum current consumed by a system

DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
D-4
DT01-S 25 29
PF01-S 55 -
02TKL-S 75
-
02TKN-S 55
-
02TKR-S 60
-
D.1.4 Current consumption of a left-side high-speed special module (+24VDC)
Model
Internal maximum current
consumed by the IO-BUS (mA)
Maximum current consumed by
the external DIO (A)
01LC-SL 40 125
02LC-SL 40 125
02PU-SL 45 -
04AD-SL 40 15
04DA-SL 40 80
COPM-SL 50 0
DNET-SL 50 26
201LC-SL 100 -
202LC-SL 140 -
211LC-SL 150 4030
EN01-SL 62.5 0
PF02-SL 60
-
SCM12-SL 62.5
-
SCM52-SL 62.5
-
D.1.5 Calculating the maximum current consumed by a system
Example: 28SV2 + 16SP + 04AD-S + 04TC-S + EN01-SL
The power module optionally purchased is DVPPS02. (It supplies 2A current.)
Model
Internal current consumption
External current consumption
DVP28SV11T2
170mA
3.8A
DVP16SP11R
65mA
5A
DVP04AD-S
30mA
83mA
DVP04TC-S
30mA
83mA
DVPEN01-SL
60mA
0
Maximum current consumed: Internal  170 + 65 + 30 + 30 + 60 = 355 (mA) < 2A Pass
External  3.8A + 5A + 83mA + 83mA = 9A > 2A Not pass
Conclusion: The 2A current supplied by DVPPS02 is sufficient for the PLC and the special modules.
If the external I/O terminals are connected to loads, it is suggested that users should
purchase an extra power module.
