3. Instruction Set
Explanations on associated flags and registers:
1. Description on associated flags:
For M1029, M1030, M1102, M1103, M1078, M1079, M1104, M1105, M1538, M1539, M1540,
M1541, M1347, M1348, M1524, M1525, please refer to PLSY instruction.
M1108: Y0 pulse output pause (ramp down). ON = pause, OFF = resume
M1109: Y1 pulse output pause (ramp down). ON = pause, OFF = resume
(Not available for EC5)
M1110: Y2 pulse output pause (ramp down). ON = pause, OFF = resume
M1111: Y3 pulse output pause (ramp down). ON = pause, OFF = resume
(Not available for EC5)
M1133: Y4 pulse output pause (ramp down). ON = pause, OFF = resume
(Applicable to EC5)
M1134: Y6 pulse output pause (ramp down). ON = pause, OFF = resume
(Applicable to EC5)
M1156: Enabling the mask and alignment mark function on I400/I401(X4) corresponding to
Y0.
M1257: Set the ramp up/down of Y0, Y2 to be “S curve.” ON = S curve.
M1158: Enabling the mask and alignment mark function on I600/I601(X6) corresponding to
Y2.
M1534: E
nable ramp-down time setting on Y0. Has to be used with D1348.
M1535: Enable ramp-down time setting on Y2. Has to be used with D1349.
M1536: Enable ramp-down time setting on Y4. Has to be used with D1350.
(Applicable to EC5)
M1537: Enable ramp-down time setting on Y6. Has to be used with D1351.
(Applicable to EC5)
2. Description on associated special registers:
For D1030~D1033, D1336~D1339, D1220, D1221, please refer to PLSY instruction
D1026: M1156 = ON, D1026 stores pulse number for masking Y0 (Low word).
D1027: M1156 = ON, D1026 stores pulse number for masking Y0 (High word).
D1135: M1158 = ON, D1135 stores pulse number for masking Y2 (Low word).
D1136: M1158 = ON, D1135 stores pulse number for masking Y2 (High word).
D1232: Output pulse number for ramp-down stop when Y0 mark sensor receives signals.
(Low word).
D1233: Output pulse number for ramp-down stop when Y0 mark sensor receives signals.
(High word).
D1234: Output pulse number for ramp-down stop when Y2 mark sensor receives signals
(Low word).
