Delta DVP-EX2 User Manual

3. Instruction Set
3-227
The following table shows the state of the output point Y when the high-speed counter C251
reaching 8000.
Output point Y number Y0 Y1 Y2
Output state OFF OFF OFF
Device D number D2000 D2001 D2002
Value of the head index
(16-bit)
K4 K4 K4
Device D number D2003 D2004 D2005
Value of the tail index (16-bit) K4 K4 K3
The following table shows the state of the output point Y when the high-speed counter C251
reaching 8700.
Output point Y number Y0 Y1 Y2
Output state OFF OFF ON
Device D number D2000 D2001 D2002
Value of the head index
(16-bit)
K4 K4 K4
Device D number D2003 D2004 D2005
Value of the tail index (16-bit) K4 K4 K4
