Delta DVP-EX2 User Manual

3. Instruction Set
3-529
API Mnemonic Operands Function
Controllers
ES2/EX2/
EC5
SS2
SA2
SE
SX2
166 TRD P
Time read
Type
OP
Bit Devices Word devices Program Steps
X
Y
M
S
K
H
KnX
KnY
KnM
KnS
T
C
D
E
F
TRD, TRDP: 3 steps
D
*
*
*
PULSE
16-bit
32-bit
ES2/EX2/
EC5
SS2
SA2
SE
SX2
ES2/EX2/
EC5
SS2
SA2
SE
SX2
ES2/EX2/
EC5
SS2
SA2
SE
SX2
Operand:
D: Current time of RTC (occupies 7 consecutive devices)
Explanations:
1. TRD instruction reads the 7 real-time data of RTC (year (A.D.), day(Mon.Sun.), month, day,
hour, minute, second from D1319~D1313 and stores the read data in registers specified by D.
2. Only when power is on can RTCs of SS2 series perform the fuction of timing. The RTC data
registers D1319~D1313 are latched. When power is resumed, the RTC will resume the stored
time value before power down. Therefore, we suggest users modify the RTC value every time
when power is ON.
3. RTCs of SA2/SE V1.0 及 ES2/EX2/SX2 V2.0 series can still operate for one or two weeks after
the power is off (they vary with the ambient temperature). Therefore, if the machine has not
operated since one or two weeks ago, please reset RTC.
4. D1319 only stores the 2-digit year in A.D. If 4-digit year data is required, please refer to Points
to note below.
5. For relative flags and registers please refer to Points to note.
Program Example:
When X0 = ON, TRD instruction reads the current time of RTC to the specified register D0~D6.
The content of D1318: 1 = Monday; 2 = Tuesday … 7 = Sunday.
X0
TRD D0
Special D
Item
Content
Normal D
Item
D1319
Year (A.D.)
00~99
→
D0
Year (A.D.)
D1318
Day (Mon.~Sun.)
1~7
→
D1
Day (Mon.~Sun.)
D1317
Month
1~12
→
D2
Month
D1316
Day
1~31
→
D3
Day
D1315
Hour
0~23
→
D4
Hour
D1314
Minute
0~59
→
D5
Minute
D1313
Second
0~59
→
D6
Second
