Delta DVP-EX2 User Manual

3. Instruction Set
3-549
API Mnemonic Operands Function
Controllers
ES2/EX2/
EC5
SS2
SA2
SE
SX2
187 MBWR P Matrix bit write
Type
OP
Bit Devices Word devices Program Steps
X Y M S K H KnX KnY KnM KnS T C D E F
MBWR, MBWRP: 7 steps
S
*
*
*
*
*
*
*
n
*
*
*
D
*
*
*
*
*
*
*
*
PULSE
16-bit
32-bit
ES2/EX2/
EC5
SS2
SA2
SE
SX2
ES2/EX2/
EC5
SS2
SA2
SE
SX2
ES2/EX2/
EC5
SS2
SA2
SE
SX2
Operands:
S: Matrix source device n: Matrix length (K1~K256) D: Pointer Pr (bit number).
Explanations:
1. MBWR instruction writes the bit status of the matrix. When MBWR executes, the status of
M1094 (Matrix pointer clear flag) will be checked first. If M1094 = ON, Pr value in D will be
cleared and the instruction writes from the first bit. The bit status of M1096 (Borrow flag for
matrix operation) is written into the first bit of the matrix. After a bit is written, MBWR checks
the status of M1093 (Matrix pointer increasing flag). If M1093 = ON, MBWR instruction will
proceed to write the next bit, i.e. Pr value plus 1. When MBWR proceeds to the last bit, M1089
= ON, indicating the end of the Matrix, and D records the last bit number. After this, MBWR
instruction stops.
2. The Pointer (Pr) of the matrix is designated by the user in the instruction. The valid range of Pr
is 0 ~ 16n -1, corresponding to b0 ~ b16n-1 in the matrix. If the Pr value exceeds the valid
range, M1092 = ON and the instruction will be disabled.
3. If operands S or D use KnX, KnY, KnM, KnS format, only n = 4 is applicable.
Program Example:
1. When X0 goes from OFF→ON with M1094 = OFF (Starts from Pr value) and M1093 = ON
(Increase Pr value), the writing will start from the bit number in Pr and Pr value increases 1
after a bit is written.
2. Assume present value of pointer D20 = 45 and M1096 = ON (1) , the following result can be
obtained when X0 is executed once from OFF→ON.
X0
MBWRP D0 K3 D20
