Delta DVP-EX2 User Manual

3. Instruction Set
3-597
API Mnemonic Operands Function
Controllers
ES2/EX2
/EC5
SS2
SA2
SE
SX2
274 D
BORI
Connect NC Contact in Parallel
by Specified Bit
Type
OP
Bit Devices Word devices Program Steps
X Y M S K H KnX KnY KnM KnS T C D E F
BORI: 5 steps
DBORI: 9 steps
S
*
*
*
*
*
*
n
*
*
*
*
*
*
*
*
*
*
*
PULSE
16-bit
32-bit
ES2/
EX2/
EC5
SS2
SA2/
SE
SX2
ES2/
EX2/
EC5
SS2
SA2/
SE
SX2
ES2/
EX2/
EC5
SS2
SA2/
SE
SX2
Operands:
S: Reference source device n: Reference bit
Explanations:
17. For ES2/EX2 models, only V1.20 or above supports the function
18. Available range for the value in operand n: K0~K15 for 16-bit instruction; K0~K31 for 32-bit
instruction.
BORI instruction is used to connect NC contact in parallel, whose state is defined by the reference
bit n in reference device D, i.e. if the bit specified by n is ON, the NC contact will be ON, and
vice versa.
Program Example:
X0
Y1
BORI D0 K0
Instruction: Operation:
LD X0 Load NO contact X0
BORI D0 K0 Connect NC contact in
parallel, whose state is
defined by bit0 of D0
OUT Y1 Drive coil Y1
