DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
3-600
API Mnemonic Operands Function
Controllers
ES2/EX2
/EC5
SS2
SA2
SE
SX2
281~
286
FAND※
Floating Point Contact Type
Comparison AND※
Type
OP
Bit Devices Word devices Program Steps
X Y M S K H KnX KnY KnM KnS T C D E F
FAND※: 9 steps
S
1
*
*
*
S
2
*
*
*
PULSE
16-bit
32-bit
ES2/
EX2/
EC5
SS2
SA2/
SE
SX2
ES2/
EX2/
EC5
SS2
SA2/
SE
SX2
ES2/
EX2/
EC5
SS2
SA2/
SE
SX2
Operands:
S
1
: Source device 1 S
2
: Source device 2
Explanations:
1. This instruction compares the content in S
1
and S
2
. Take “FAND =” for example, if the result is
“=”, the continuity of the instruction is enabled. If the result is “≠”, the continuity of the instruction
is disabled.
2. The user can specify the floating point value directly into operands S
1
and S
2
(e.g. F1.2) or
store the floating point value in D registers for further operation.
3. FAND※ instruction is used for serial connection with contacts.
API No.
32-bit instruction
Continuity condition
Discontinuity condition
281
FAND
＝
S
1
＝
S
2
S
1
≠S
2
282
FAND＞
S
1
＞S
2
S
1
≦S
2
283
FAND
＜
S
1
＜
S
2
S
1
≧S
2
284
FAND＜＞
S
1
≠S
2
S
1
＝S
2
285
FAND
＜＝
S
1
≦S
2
S
1
＞
S
2
286
FAND＞＝
S
1
≧S
2
S
1
＜S
2
Program Example:
When X1 is OFF and the content in D100(D101) is not equal to F1.2, Y21 = ON and latched.
FAND<>
F1.2 D0
SET Y21
X1
