DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
1 = Homing in the reverse direction; NL
original point.
2 = Homing in the forward direction; ORGP: OFF >
ON, as the original point.
3 = Homing in the reverse direction; ORGP: OFF >
ON, as the original point.
4 = Homing in the forward direction; look for Z pulse
and regard it as the original point.
5 = Homing in the reverse direction; look for Z pulse
and regard it as the original point.
6 = Homing in the forward direction; ORGP: ON >
OFF, as the original point.
7 = Homing in the reverse direction; ORGP: ON >
OFF, as the original point.
8 = Current position is the original point.
Homing method: 9~A
9 = Homing in the forward direction; the collision
point is the original point.
A = Homing in the reverse direction; the collision
point is the original point.
