DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
2-42
Special
D
Content
ES2
EX2
EC5
SS2
SA2
SE
SX2
OFF

ON
STOP

RUN
RUN

STOP
Attrib.
Latch
-ed
Default
D1220
Output mode setting for the 1
st
group pulse
CH0 (Y0, Y1)
○ ○ ○ ○
0 - - R/W NO 0
D1221
Output mode setting for the 2
nd
group
pulse CH1 (Y2, Y3)
○ ○ ○ ○
0 - - R/W NO 0
D1222
Output mode setting for the 3
rd
group pulse
CH2 (Y4, Y5)
EC5
╳
╳ ╳
0 - - R/W NO 0
D1223
Output mode setting for the 4
th
group pulse
CH3 (Y6, Y7)
EC5
╳
╳ ╳
0 - - R/W NO 0
D1227
D1228
Sender’s IP address when executing
ETHRS instruction in receiving mode
(available for ES2-E: V1.2, 12SE: V1.92,
26SE: V2.00)
ES2-C
╳
SE
╳
0 0 - R NO 0
D1229~
D1231
Network MAC address (hexadecimal
format ex: 12:34:56:78:9A:BC =>
D1229=H'1234, D1230=H'5678,
D1231=H'9ABC) (available for ES2-E:
V1.2, 12SE: V1.92, 26SE: V2.00)
ES2-C
╳
SE
╳
0 0 - R YES 0
D1232*
Number of output pulses for CH0 (Y0, Y1)
ramp-down stop when mark sensor
receives signals. (Low word).
ES2/
EX2
○ ○ ○
0 0 -- R/W NO 0
D1233*
Number of output pulses for CH0 (Y0, Y1)
ramp-down stop when mark sensor
receives signals. (High word).
ES2/
EX2
○ ○ ○
0 0 -- R/W NO 0
D1234*
Number of output pulses for CH1 (Y2, Y3)
ramp-down stop when mark sensor
receives signals. (Low word).
ES2/
EX2
○ ○ ○
0 0 -- R/W NO 0
D1235*
Number of output pulses for CH2 (Y2, Y3)
ramp-down stop when mark sensor
receives signals. (High word).
ES2/
EX2
○ ○ ○
0 0 -- R/W NO 0
D1240*
When interupt I400/I401/I100/I101 occurs,
D1240 stores the low word of high-speed
counter.
○ ○ ○ ○
0 0 - R NO 0
D1241*
When interupt I400/I401/I100/I101 occurs,
D1241 stores the high Word of high-speed
counter.
○ ○ ○ ○
0 0 - R NO 0
D1242*
When interupt I500/I501/I300/I301 occurs,
D1242 stores the low Wordof high-speed
counter.
○ ○ ○ ○
0 0 - R NO 0
D1243*
When interupt I500/I501/I300/I301 occurs,
D1243 stores the high Word of high-speed
counter.
○ ○ ○ ○
0 0 - R NO 0
D1244
Idle time (pulse number) setting
of CH0 (Y0,
Y1) The function is disabled if set value≦0.
○ ○ ○ ○
0 - - R/W NO 0
D1245
Idle time (pulse number) setting of CH1 (Y2,
Y3) The function is disabled if set value≦0.
○ ○ ○ ○
0 - - R/W NO 0
D1246*
Low word of X2’s input pulse frequency
(Unit: 0.01Hz) It is used with M1359,
available for
ES2/EX2: V3.22, ES2-C:
V3.68, SA2: V3.02, SX2: V2.66 or later
ES2/
EX2
╳
SA2
○
0 0 - R NO 0
D1247*
High word of X2’s input pulse frequency
(Unit: 0.01Hz) It is used with M1359,
available for
ES2/EX2: V3.22, ES2-C:
V3.68, SA2: V3.02, SX2: V2.66 or later
ES2/
EX2
╳
SA2
○
0 0 - R NO 0
D1248
Enter the number of input points on DIO
module for the PLC to check if the number
is matched with the value in D1142 when
power-on. Available for ES2/EX2/ES2C:
V3.62, ES2E: V1.48 or later
ES2/
EX2
╳ ╳ ╳
- - - R/W YES 0
D1249
Set value for COM1 (RS-232) data
receiving time-out (Unit: 1ms, min. 50ms,
value smaller than 50ms will be regarded
as 50ms) (only applicable for MODRW/RS
instruction) In RS instruction, no time-out
setting if “0” is specified.
○ ○ ○ ○
0 - - R/W NO 0
D1250
COM1 (RS-232) communication error code
(only applicable for MODRW/RS
instruction)
○ ○ ○ ○
0 - - R/W NO 0
