API Mnemonic Operands Function
Controllers
ES2/EX2
SS2
SA2
SE
SX2
353 PUX P Module~ErrCode
Setting PU module input point
mode
Type
OP
Bit Devices Word devices Program Steps
X
Y
M
S
K
H
KnX
KnY
KnM
KnS
T
C
D
E
F
PUX, PUXP: 15 steps
(To be used in ISPSoft)
Module
*
*
*
Xno
*
*
*
Xmode
*
*
*
Xfilter
*
*
*
Done
*
*
*
Error
*
*
*
ErrCode
*
PULSE
16-bit
32-bit
ES2/EX2 SS2
SA2
SE
SX2 ES2/EX2 SS2
SA2
SE
SX2 ES2/EX2 SS2
SA2
SE
SX2
Operands:
Module: Module number Xno: Input point number Xmode: Input point mode
Xfilter: Input point filter time Done: Completion flag Error: Error flag ErrCode: Error code
Explanations:
1. This instruction is available for ES2/EX2 (FW V4.02 or later) and ES2-E (FW V1.48 or later).
For ISPSoft, we recommend using software version 3.16 and above. When En setting is set to
ON, this instruction would be effective. Once the setting changes to OFF, Output pulse would
be terminated immediately. WPLSoft does NOT support this instruction.
2. Module sets the serial number of modules at the right of the PLC. The first one is number 0,
the second one is number 1 and so on. Whatever modules at the right of the PLC must be
numbered. The maximum number is 8. The instruction is exclusive to the PU modules at the
right of the PLC. If the specified module is not a PU module, the error flag Error will change to
ON.
3. Xno sets the input point number for the PU module with one of the input values 0~4 which
respectively represent the input points X0~X4. If there is no correspoing input point in the PU
module, the error flag Error will change to ON. The value in Xno and the corresponding input
point are listed in the following table.
Setting in
Xno
0 1 2 3 4 Others
DVP02PU-E2 X0 X1 X2 X3 X4 No input point
