DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
B-16
Refer to Config Data below
Connection 5
Refer to Config Data below
Connection 6
Refer to Config Data below
Connection 7
Refer to Config Data below
Connection 8
Refer to Config Data below
Config Data
Input Device Type INT
Input (T to O) device type
0: D register
0
Input (T to O) device quantity
Input Device Address DINT
Input (T to O) device address
0: D0,
Refer to
Connection 1 ~ 8
Output Device Type INT
Output (O to T) device type
0：D register
0
INT Output (O to T) device quantity 100
Output Device
Address
DINT
Output (O to T) device address
0: D0,
Refer to
Connection 1 ~ 8
(4) X input
DVP12SE: (0x64)
ES2-E & DVP26SE: (0x350)
(5) Y output
DVP12SE: (0x65)
