Delta DVPSCM Series User Manual

Communication Module DVPSCM12/52-SL
DVP-PLC Operation Manual
12
CR#39~40: Selcting the “reading bits through COM2” checkbox
[Description]
Select the “reading bits through COM2” checkbox. The SCM module can read at most 32 groups of data
(No.1~No.32).
CR#39: No.16~No.1; CR#40: No.32~No.17
0: Enable the function; 1: Disable the function
CR#41~42: Selecting the “reading words through COM2” checkbox
[Description]
Select the “reading words through COM2” checkbox. The SCM module can read at most 32 groups of data
(No.1~No.32).
CR#41: No.16~No.1; CR#42: No.32~No.17
0: Enabling the function; 1: Disabling the function
CR#43~44: Selecting the “writing bits through COM1” checkbox
[Description]
Select the “writing bits through COM1” checkbox. The SCM module can write at most 32 groups of data
(No.1~No.32).
CR# CR43
Bit b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
No. 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
CR#43: No.16~No.1; CR#44: No.32~No.17
0: Enabling the function; 1: Disabling the function
CR#45~46: Selecting the “writing words through COM1” checkbox
[Description]
Select the “writing words through COM1” checkbox. The SCM module can write at most 32 groups of data
(No.1~No.32).
CR#45: No.16~No.1; CR#46: No.32~No.17
0: Enabling the function; 1: Disabling the function
CR#47~48: Selecting the “writing bits through COM2” checkbox
[Description]
Select the “writing bits through COM2” checkbox. The SCM module can write at most 32 groups of data
(No.1~No.32).
CR#47: No.16~No.1; CR#48: No.32~No.17
